Wafer Lift Check Valve

Lub wafer nqa daim tshev valve yog tsim los ntawm lub cev lub cev, lub valve disc, lub caij nplooj ntoos hlav, thiab lwm yam, thiab tau nruab rau hauv kab rov tav lossis ntsug hauv cov raj xa dej kom tsis txhob rov qab los ntawm qhov nruab nrab.

Wafer nqa check li qub yog siv dav hauv cov dej xa dej thiab cov kav dej, kev tiv thaiv hluav taws, kev tsim kho, HVAC, thiab cov tshuab ua haujlwm. Dej, roj, roj, kua qaub, alkali, hydrogen, ammonia, cov kav dej tshwj xeeb thiab lwm yam xov xwm tuaj yeem siv tau. Piv txwv li: nws tuaj yeem ntsia tau rau ntawm qhov hluav taws xob ntawm lub twj tso kua dej kom tsis txhob muaj dej rauj, dej rauj lub suab thiab kev puas tsuaj, tiv thaiv kev rov qab los thiab tiv thaiv cov khoom siv, thiab muaj kev txuag hluav taws xob zoo dua.

Loj: 1/2" -10", DN 15-DN250
Kev ntsuas siab: Chav 150-Class900, PN10-PN160
Cov khoom tseem ceeb: WCB, LCB, CF8, CF8M, CF3, CF3M, A890 4A, A890 5A
Cov khoom siv caij nplooj ntoos hlav: 316, Inconel x750, Inconel 718 thiab lwm yam

Wafer kos valve specifications thiab qhov ntev ntawm lub rooj

Nominal siab MPa	Nominal txoj kab uas hla DN	Loj (mm)
Nominal siab MPa	Nominal txoj kab uas hla DN	L	D1	D2	D3	D4	D5
PN1 0MPa PN 1.6MPa	15	16	52	15	24	31	40
	20	19	62	19	30	40	50
	25	22	72	24	35	47	58
	32	28	83	31	46	56	68
	40	31.5	93	39	55	66	78
	50	40	108	48	65	78	90
	65	46	128	62	80	95	110
	80	50	142	76	96	110	128
	100	60	162	95	115	132	150
	125	90	192	110	125	135	-

Main technical parameters

Hom	PN (MPa)	PS (MPa)		Ua haujlwm kub (degree)	Siv tau xov xwm
		Case	foob
H71W-16P	1.6	2.4	1.76	Tsawg dua los yog sib npaug li 200	Dej, chav, roj, thiab lwm yam.
H71H-25Q	2.5	3.75	2.75	Tsawg dua lossis sib npaug li 235
H71W-25H				Tsawg dua los yog sib npaug li 300
H71W-25P				Tsawg dua los yog sib npaug li 200	Corrosive media xws li nitric acid
H71W-40H	4.0	6.0	4.4	Tsawg dua los yog sib npaug li 300	Dej, chav, roj, thiab lwm yam.
H71W-40P				Tsawg dua los yog sib npaug li 200	Corrosive media xws li nitric acid

Wafer check valve

Check Valve Cast steel check valve
