Lub valve disc ntawm lub cam khwb cia hlau nqa kos valve ua haujlwm tau txais. Feem ntau, lub conical valve disc yog nias tawm tsam lub rooj zaum hlau valve nyob nruab nrab ntawm qhov nkag thiab qhov hluav taws xob ntawm lub valve. Lub caij nplooj ntoos hlav tuaj yeem ntxiv rau lub valve disc rau preload. Thaum cov kua ntws mus rau pem hauv ntej, cov kua siab ua rau lub conical valve disc tawm ntawm lub rooj zaum valve, yog li qhib lub valve. Thaum cov kua dej ntws rov qab, lub valve disc rov qab mus rau lub rooj zaum valve vim nws qhov hnyav, lub caij nplooj ntoos hlav quab yuam (yog tias preload tau thov), thiab cov kua rov qab siab, ua rau lub valve kaw.
Khoom Specification
Technical Specification:
Nominal Diameter: DN 40-600
Nominal Siab: PN 10-16
Tus Qauv Tsim: BS5153 / MSS SP-71
FTF Dimension: DIN EN3202-F6/ASME B16.10
Flange Txuas: ASME B16.1 CL125 / EN1092 PN 10-16
Kev soj ntsuam thiab kuaj: API598 / EN12266
Vijtsam kos Valve cov khoom npe
1. Lub cev: Cam khwb cia hlau GG25
2. Disc: Cam khwb cia hlau GG25
3. Lub rooj zaum nplhaib: tooj dag
4. Disc Nplhaib: Brass / EPDM
5. Hanger: Hlau Hlau GGG50
6. Hanger Pin: Stainless hlau 2Cr13
7. Gasket: Graphite+304/EPDM
8. Stud thiab txiv ntseej: A194B8-8/B7-2H
Cast Iron Lift Check Valve
FAQ
Q: Dab tsi yog qhov kev coj ua ntawm koj cov khoom?
A:Peb tshwj xeeb hauv JIS, DIN, thiab API cov qauv. Peb tuaj yeem tuav vuam, stamping, ntawv hlau, laser txiav, thiab lwm yam khoom siv kho vajtse raws li cov duab kos lossis cov qauv.
Q: Koj lub Hoobkas puas muaj Tshuag? Koj lub sijhawm xa khoom ntev npaum li cas?
A:Peb muaj li qub li qub hauv Tshuag. Lub sij hawm xa khoom dav dav yog 7-15 hnub. Yog tias cov khoom tsis muaj Tshuag, lub sijhawm khoom xa tuaj yuav yog 35-40 hnub, nyob ntawm qhov kev txiav txim kom muaj nuj nqis.
Q: Lub teb chaws twg koj xa mus rau?
A:Peb lub valve loj tau raug xa tawm mus rau ntau dua 150 lub teb chaws thoob ntiaj teb thiab hauv cheeb tsam, suav nrog Chile, Fabkis, UK, Asmeskas, Nyab Laj, UAE, Kazakhstan, Kyrgyzstan, thiab lwm yam.
Q: Koj puas tuaj yeem muab cov ntaub ntawv tseem ceeb thiab daim ntawv pov thawj?
A:Yog lawm, peb tuaj yeem muab cov ntawv pov thawj thoob ntiaj teb raws li cov neeg siv khoom xav tau.
Q: Koj puas muab cov qauv?
A:Yog, peb txais tos cov qauv txiav txim los kuaj thiab xyuas cov khoom zoo.
Q: Koj puas tuaj yeem muab kev pabcuam OEM lossis ODM?
A:Yog, peb muaj ib pab neeg R & D muaj zog. Cov khoom tuaj yeem ua raws li koj qhov yuav tsum tau ua.
Q: Cov nqe lus them nqi yog dab tsi?
A:30% T / T ua ntej, nrog rau 70% tshuav nyiaj them ua ntej xa khoom lossis tawm tsam daim C / L.
Cim npe nrov: Tuam Tshoj cam khwb cia hlau nqa check valve, Tuam Tshoj cam khwb cia hlau nqa check valve manufacturers, lwm tus neeg, Hoobkas
