Lub valve qia axis ntawm triple eccentric lug npauj npaim valve deviates los ntawm qhov chaw ntawm lub disc thiab qhov chaw ntawm lub cev ib txhij, thiab lub valve lub rooj sib hloov axis yog nyob rau ntawm ib tug tej lub kaum sab xis rau lub valve lub cev channel axis. Nws yog dav siv nyob rau hauv industrial pipelines, xws li nyob rau hauv metallurgy, hluav taws xob fais fab, petrochemical, dej mov thiab tso dej, thiab kev tsim kho hauv nroog, nrog rau qhov nruab nrab kub tsawg dua los yog sib npaug li 425 degree, los kho cov dej ntws thiab txiav tawm. Nws cov khoom muaj xws li cam khwb cia hlau, cam khwb cia hlau, stainless hlau, thiab lwm yam.
Khoom Specification
Khoom siv lub cev: Cam khwb cia hlau, Hlau Hlau, Carbon hlau
Cov ntaub ntawv Disk: Cov Hlau Stainless, Nylon 5/11 Coated Ductile Iron, Txhuas Bronze, Stainless Hlau, Hastelloy, Halar Coated Ductile Iron
Cov khoom siv: Carbon steel, Stainless hlau, Monel
Cov Khoom Siv Lub Rooj: (NBR & Nitrile), EPDM, HTEPDM, FKM, Cov Rooj zaum dawb rau cov ntawv thov zaub mov
Daim ntaub ntawv: Cov dej haus, dej khib nyiab, HVAC, Irrigation, Metallurgy, Fais Fab, Marine, Roj & Gas, Pulp & Ntawv, Tej Khoom, Mining, Khoom noj khoom haus & dej haus
Cov khoom muaj nyob ntawm valve loj & series. Lwm cov ntaub ntawv muaj nyob. Thov sab laj nrog peb lossis koj tus neeg sawv cev AVANNTO hauv zos rau koj qhov xwm txheej tshwj xeeb.
Nominal txoj kab uas hla: DN 50 - DN 1200
Ntsej muag ntsej muag: EN 558 Series 20, ISO 5752 Series 20, API 609 Table 1
Flange kev pab: EN 1092 PN 6/10/16, ASME Class 150, AS 4087 PN 16
Flange Surface Design: EN 1092 Daim Ntawv A / B, ASME RF, FF
Sab saum toj flange: EN ISO 5211
Tightness check: EN 12266 (Leakage rate A), ISO 5208, Qeb 3
Cov qauv ua haujlwm: EN 593
Qhov kub thiab txias: -10 degree rau + 130 degree (nyob ntawm qhov siab, nruab nrab thiab cov khoom siv)
Max. Ua haujlwm siab: max. 16 bar
Triple Eccentric Npauj Npaim Valve Lug Hom
FAQ
1. Koj puas yog lub tuam txhab lag luam lossis lub Hoobkas?
Peb yog lub Hoobkas tsim, thiab peb kuj muaj peb tus kheej daim ntawv tso cai xa tawm.
2. Koj puas muaj daim ntawv pov thawj?
Yog lawm, peb muaj ISO, FDA, LFGB, CE, thiab PED daim ntawv pov thawj. Peb kuj muaj qee qhov tsim patents.
3. Koj tswj tau qhov zoo li cas?
Hauv kev tswj kom zoo, qhov tseem ceeb tshaj plaws yog kom tsis txhob muaj cov khoom sib xyaw. Hauv peb lub Hoobkas, peb siv peb lub tshuab Spectro PMI hauv cov khoom siv raw khoom, chaw tsim khoom, thiab chaw xa khoom. Tsis tas li ntawd, peb siv cov tshuab ntsuas siab, PMI tshuab, RA roughness observers, thiab hardness test machines rau kev tshuaj xyuas.
4. Koj lub sijhawm xa khoom ntev npaum li cas?
Rau cov khoom qub, nws yog 7-10 hnub; rau kev txiav txim ntau, nws yog 15-25 hnub. Nws nyob ntawm qhov xwm txheej.
5. Lub sijhawm lav?
Tag nrho peb cov khoom lag luam stainless hlau muaj 3- xyoo lav. Txawm li cas los xij, cov tshuab ntxhua khaub ncaws lossis cov khoom puas yooj yim tsis suav nrog vim kev siv sib txawv los ntawm cov neeg siv khoom.
Cim npe nrov: triple eccentric npauj npaim valve lug hom, Tuam Tshoj triple eccentric npauj npaim valve lug hom manufacturers, lwm tus neeg, Hoobkas
