Lub Jacketed nres valve yog qhov yuam kev sealing valve, yog li thaum lub valve raug kaw, lub siab yuav tsum tau siv rau lub valve disc kom yuam lub sealing nto tsis txhob xau. Thaum qhov nruab nrab nkag mus rau hauv lub valve los ntawm hauv qab lub valve disc, qhov kev tawm tsam uas kev khiav hauj lwm quab yuam yuav tsum tau kov yeej yog kev sib txhuam ntawm lub valve qia thiab cov packing thiab thrust generated los ntawm lub siab ntawm nruab nrab. Lub zog kaw lub valve ntau dua qhov quab yuam kom qhib lub valve, yog li lub valve Txoj kab uas hla ntawm qia yuav tsum loj, txwv tsis pub lub qia valve yuav khoov.
Chaw nres nkoj loj:DN15 x DN 40-DN150 x DN250
Nruab nrab:Raws li cov neeg siv khoom xav tau
Kub:-40-450 degree
| Khoom siv lub cev | WCB CF8 CF3 CF8M CF3M lossis lwm yam |
| Xaus | Flanged kawg, Screwed xaus |
| Tsav tsheb hom | Phau ntawv, Hluav taws xob, Hydraulic |
| Siab | PN16 ~ 100,150LB ~ 600LB |
| Automation Qib | Phau ntawv |
| Hom kev sib txuas | Flange, Vuam, Xov |
| Loj | 1/2 txog 24 nti |
Globe Valve Size Table
|
Loj |
DN |
15 |
20 |
25 |
32 |
40 |
50 |
65 |
80 |
100 |
125 |
150 |
|
L |
mm |
170 |
190 |
210 |
230 |
260 |
300 |
340 |
380 |
430 |
490 |
550 |
|
H |
mm |
250 |
292 |
340 |
348 |
360 |
410 |
440 |
548 |
560 |
625 |
720 |
|
W |
mm |
120 |
140 |
160 |
160 |
160 |
240 |
240 |
280 |
320 |
360 |
360 |
|
G |
Ntiv |
3/8" |
3/8" |
3/8" |
1/2" |
1/2" |
1/2" |
1/2" |
1/2" |
1/2" |
1/2" |
1/2" |
Jacketed ntiaj teb li qub tau muab faib ua peb pawg: ncaj-dhau, txoj cai-lub kaum sab xis thiab DC inclined nres li qub.
Jacketed Steel Globe Valve
