Cam khwb cia hlau riam rooj vag valve txais lub hauv qab ntawm lub valve lub cev sealing, tsis muaj groove nyob rau hauv lub valve kab noj hniav, tsis yooj yim rau thaiv, tsis muaj residue, yooj yim los ntxuav lub pipeline, flange sealing nto teeb O-ring, tsis tas yuav tsum tau rau lwm flange gaskets. , yooj yim thiab yooj yim installation, kev sib txhuam coefficient me me, qhib thiab kaw qhov hloov tau yooj yim, cov riam rooj vag valve no tuaj yeem nruab nrog phau ntawv, hluav taws xob, pneumatic, electro-hydraulic, pneumatic, kaus iav tsav, thiab ntau yam actuators, hauv kom ua tau raws li qhov yuav tsum tau muaj ntawm cov mines sib txawv thiab kev lag luam siv.
Cam khwb cia hlau riam rooj vag Valve Specification
Siv tau Standard
Tus Qauv Tsim: MSS SP-81, ANSI, API, ISO, DIN, EN, JIS thiab lwm yam.
Flange kawg: ASME B16.5, ASME B16.47, DIN2533
Qhov ntau thiab tsawg
2 "mus rau 40" (DN50 rau DN1000)
Kev ntsuas siab
PN10, PN16, ANSI 125 & ANSI 150
Kev ua haujlwm
Handwheel, Iav, Pneumatic, Hydrau-Pneumatic thiab Hluav Taws Xob thiab lwm yam.
Khoom siv
Cam khwb cia hlau, Cov Hlau Hlau, Cam khwb cia hlau, Stainless hlau, Duplex thiab tshwj xeeb Alloys
| Loj (mm) | Siab Ntau | Media kub | Qhov hnyav (kg) |
|---|---|---|---|
| 50 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 6 |
| 65 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 8 |
| 80 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 9 |
| 100 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 11 |
| 125 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 20 |
| 150 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 21 |
| 200 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 30 |
| 250 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 50 |
| 300 | 0 mus rau 10 BAR | 0 degree rau 80 degree | 60 |
Riam rooj vag Valve
