Nozzle Check Valves

Lub nozzle check valve yog ib qho uas tsis yog-shutoff check valve thiab ib tug high-kev ua tau zoo tus kheej-tsav regulating ntaus ntawv. Cov check valves txhim khu kev qha no yog tsim los rau cov ntawv thov. Qhov no txhais tau hais tias lawv tuaj yeem hnov mob sai sai rau kev txo qis qis nrog kev ua haujlwm tsis zoo, txo cov dej rauj hauv cov dej ntws rov qab.

Nozzle check li qub muaj lub caij nplooj ntoos hlav-pab, luv-stroke disc ua haujlwm uas kaw lub valve hauv ib feem ntawm ib pliag. Cov yeeb yam no tiv thaiv cov kav dej, cov twj siv hluav taws xob kim thiab cov khoom siv cuam tshuam los ntawm kev rov qab nrawm nrawm thiab ua rau muaj kev puas tsuaj rau lub zog siab.

Tsim & Tsim los rau API 6D, API 594, ASME B16.34 lossis sib npaug ◆ PT Ratings rau ASME B16.34

Ntsej muag rau ntsej muag Dimensions rau API 6D Standard los yog luv qauv ◆ Flanged Ends rau ASME B16.5, Wafer xaus rau API 594

Butt-weld xaus rau ASME B16.25 ◆ Valves Marking rau MSS SP-25

Tshawb xyuas & Kuaj rau API 598 lossis API 594

Qhov ntau thiab tsawg ntawm 2 "mus rau 60"

Structured hauv One Piece Union Lub Cev

Kev ntsuas siab ntawm Chav Kawm 150 txog Chav Kawm 2500, PN16 txog PN420

Xaus kev sib txuas hauv Flanged RF lossis RTJ, Wafer, Butt-weld lossis Hub Xaus

Khoom Specifications

Lub cev (forged los yog cam khwb cia)	Nickel alloys, carbon, low-alloy, stainless thiab duplex stainless hlau
Disc (forged los yog cam khwb cia)	Nickel alloys, carbon, low-alloy, stainless thiab duplex stainless hlau
Lub cev lub rooj	Tag nrho cov API trims. Kev cai trims muaj raws li qhov kev thov.
Disc rooj	Tag nrho cov API trims. Kev cai trims muaj raws li qhov kev thov.
Sab hauv txheej	Fusion bonded epoxy los yog raws li cov neeg siv khoom
Sab nrauv txheej	Raws li cov neeg siv khoom specifications

Tsim Parameters

Nominal yeeb nkab loj	1a72 ib
Xaus kev sib txuas	Grayloc clamp connectors thiab compact flanges, ASME B16.5 flanges, ASME B16.47 flanges, ASME B16.25 weld xaus, NORSOK L-005 compact flanges, AS4087 flanges, thiab API 6A flanges Lwm qhov kawg kev sib txuas muaj raws li qhov kev thov
Tsim kev ntsuas siab	Haum rau ANSI Chav Kawm 150 txog 10, 000 psig
Tsim qhov kub thiab txias	Raws li cov khoom txwv (tag nrho cov hlau siv)
Flow orientation	Up, down, kab pheeb ces kaum, thiab kab rov tav

Kuaj Valve
